Smart Fixture Design for Modern Automotive Needs
The standard Lorem Ipsum passage, used since the 1500s “Lorem ipsum dolor sit amet, consectetur adipiscing elit, sed do eiusmod tempor incididunt ut labore et dolore magna aliqua. Ut enim...
We collaborate with the end user before manufacturing begins to ensure the fixture meets functional expectations and production realities.
Our fixtures are developed considering Gauge R&R studies, ensuring consistency across operators and repeatability in inspection.
We use swing clamps for flange and bend line checking, ensuring reliable holding with minimal deformation or displacement.
Backed by well-established C/F design standards, our fixtures are built to integrate seamlessly into your quality processes.
Using our proven pin size calculator, based on centre distances and hole size tolerances, we ensure exact part location every time.
Each fixture is designed with a deep understanding of auto panel behaviour, ensuring robust support and proper constraint at critical inspection points.
We follow the provided quality sheet and GD&T from the start of the design process, embedding specification-level accuracy into the fixture geometry.
Our designs include expansion slots and axis pockets, allowing for thermal and material variation without compromising measuring accuracy.
The clamping sequence is defined at the design stage, not left to the operator, helping reduce human error and increase consistency during part loading.
